Papad Press ( papad Rolling Machine )

Papad Press  ( papad Rolling Machine )
Papad Press ( papad Rolling Machine )
Send Inquiry
Product Code : 72
Product Description

Our organization is reckoned as one of the leading manufacturers and exporters of quality assured Papad Rolling Machine. This machine is manufactured using high grade raw materials and other components that are procured from credited vendors of the market. Our offered machine is stringently checked on various criteria like superior finish and high performance. Papad Rolling Machine is widely used in various industries for the production of papad. Clients can avail this machine at most affordable price.

Striking features:

  • Easy installation

  • Tough construction

  • Optimum functionality

  • Easy usage

Other details:

Papad Press (papad Rolling Machine)

Jas enterprises have developed a simple inexpensive foot operated press to make about 500 papad / hour from dal flour dough. The thickness of the papad altered in the machine by adjusting the clearance between the roller and polpat. Being foot operated it is simple and easy to operate. This machine adopted for cottage scale production of papad. Raw materials required for papad making are locally available in rural areas. Urad dhal, any pulse flour, salt, farinaceous material and spice mix are required. The papad industry has a good scope for marketing. Papad are exported to 42 countries from India. The preparation of papad consists of dough making using pulse flour (preferably urad dhal), salt, carbonates, farinaceous material and water. The dough is kneaded made into kinder mixture and passed in to extruder. Then it will cite with luva cutting machine. The pressed circular shaped papad is dry to 14-15% moisture level in sun light or in dryer. The above process can easily be dons at village level as it involves low investment.

Construction of pedal type papad / mathiya / chorafali making press ( papad rolling machine )

Jas handmade style papad machine consist heavy duty mild duty fabricated structure covered with stainless steel sheet. Cast iron chrome plated (stainless steel optional) palpate rotate by 0.5 h.p. (0.375 kW) electric motor. Mild steel chrome plated revolving guide having four numbers deep groove ball bearing which is drive by polpate. Moving of revolving guide is done by foot. Specialized limit switch is supplied with machine thus when revolving guide and polpate is came in contact electric motor will start.

Standard accessories of pedal type papad / mathiya / chorafali making press (papad rolling machine)

  • Machine and motor pulley

  • Adjustable motor rails.

  • Five set of pvc sheets

  • Limit switch with suitable miniature circuit breaker for single phase motor only.

Extra accessories pedal type papad / mathiya / chorafali making press (papad rolling machine)

  • Dough kneader

  • Loi (luva ) cutting machine

  • 3 meter cable and 3 pin top for single phase electric motors.

  • Starters, main switch, ampere meter, capacitor for three phase electric motor.

  • Extra PVC Sheets
